E-series — Variable speed control screw compressors with direct drive and permanent magnet motor 7.5kW to 250kW
HomeProductsAir CompressorScrew CompressorE-series — Variable speed control screw compressors with direct drive and permanent magnet motor 7.5kW to 250kW
Back to Air Compressors
Air Compressors
E-series — Variable speed control screw compressors with direct drive and permanent magnet motor 7.5kW to 250kW
Direct driven fixed-speed screw compressor
- Why choose permanent-magnetic motor driven compressors?To improve variable speed control
- To increase the efficiency of compressor operation
- To reduce the running costs
- To reduce the overall dimensions and installation space
- To eliminate the loss of speed multiplying systems
- Design Features
What can I do with a LIDA screw compressor?
The E-series from Lida Machine Equipment delivers dependable compressed air for industrial and workshop use, backed by the manufacturer's full specification sheet.
Make The Machine More User-Friendly
Easy To Move
Caster wheels and handles make repositioning the unit around the factory floor effortless.
Easy To Maintain
Accessible panels and a straightforward pump design keep servicing simple and downtime low.
Easy To Run
Clear voltage and pressure ratings make installation and daily operation straightforward.
Product Features
- Why choose permanent-magnetic motor driven compressors?To improve variable speed control
- To increase the efficiency of compressor operation
- To reduce the running costs
- To reduce the overall dimensions and installation space
- To eliminate the loss of speed multiplying systems
- Design Features
- Full side open cabinet structureFor easy maintenance
- 316 stainless steel control tubingIncrease reliability due to corrosion free
Basic Parameters
| MODEL | WORKING PRESSURE (BAR) | FAD M³/MIN | POWER | POWER (2) | NOISE DB(A) ±3 | WEIGHT (KG) | DIEMENSION(MM) LXWXH | AIR OUTLET SIZE |
|---|---|---|---|---|---|---|---|---|
| LD-10PM | 8 | 1.1 | 7.5 | 10 | 62 | 240 | 1000x735x970 | G 3/4" |
| LD-15PM | 8 | 2.0 | 11 | 15 | 65 | 300 | 1100x750x1150 | G 1" |
| LD-30PM | 8 | 3.4 | 22 | 30 | 68 | 370 | 1350x895x1150 | G 1" |
| LD-50PM | 8 | 6.2 | 37 | 50 | 70 | 505 | 1500x1000x1195 | G 1-1/2" |
| LD-75PM | 8 | 9.2 | 55 | 75 | 72 | 950 | 1800x1360x1665 | G 2" |
| LD-125PM | 8 | 15.0 | 90 | 125 | 75 | 1900 | 2000x1535x1800 | G 2" |
| LD-175PM | 8 | 22.0 | 132 | 175 | 78 | 2510 | 3200x1566x1800 | DN 65” |
| LD 60PM | 8 | 42.0 | 250 | 350 | 80 | 4300 | 3800x2270x2300 | DN 100” |
* Specifications are provided by the manufacturer and subject to change without prior notice.
