Cummins C90D5 Diesel Generator
A 6-cylinder standby genset for heavier commercial and light industrial loads — larger factories, hospitals, hotels, and telecom facilities.
The Cummins C90D5 moves up to a turbocharged, after-cooled 6BTA5.9-G5 6-cylinder engine for higher output density. It meets ISO 8528, ISO 3046, and other international rating standards, and is available in open or enclosed sound-attenuated configurations.
Standard Features
- Turbocharged and after-cooled 6-cylinder 5.9L engine
- Open or sound-attenuated, weather-protective enclosure options
- ISO 8528 / ISO 3046 / AS 2789 / DIN 6271 / BS 5514 rating compliance
- Suited to larger factories, hospitals, hotels, and telecom sites
- Wide availability across Asia Pacific, the Middle East, and Africa
Standard Specifications
Standby Rating90 kVA (72 kW)
Prime Rating82 kVA (65 kW)
EngineCummins 6BTA5.9-G5
AlternatorUCI224G, 3-Phase Wye
Fuel TypeDiesel
Frequency50 Hz
Voltage380–415V, 3-Phase
Weight (Enclosed)2,255 kg
